September 2026

+

CacheBack

+

Receiver-conditioned communication
between LLM agents.

+
+
  • Maximillian Rossi
  • Prajwal Raghunath
  • Haoqing Xuan
  • Yusen Zhang
  • Eugene Wu
+

DAP LabColumbia University

+
+

The receiver asks for what it needs.

+

CacheBack uses that request to select which internal state gets sent.

+

Our simplest implementation of receiver-conditioning: robust and training-free.

+ +
+ +
+
+

TL;DR

Read the paper
+
+
+

Written messages between agents can lose evidence; passing their entire internal state becomes expensive. Receiver-conditioning lets the receiver describe what it needs, so the sender can select what to pass on. CacheBack is our simplest, robust, training-free implementation.

+

On FanOutQA with Qwen 3 8B, CacheBack sends 75% fewer positions than full-state transfer. Compared with same-size text communication, strict accuracy improves by 14.7 percentage points and median completion is 3.2× faster.

+
+
Read the full abstract +
+

Multi-agent systems distribute large contexts across agents that communicate to solve a task. Text messages are compact but require decoding and may omit evidence the receiving agent needs. Recent latent communication instead transfers KV caches. This avoids text generation and can improve accuracy and latency. However, a full KV cache grows linearly with both the context an individual agent processes, and the number of agents that coordinate together.

+

This raises memory and context costs, often far exceeding available GPU resources and context window sizes. Our key observation is that agents need only send what the receiving agent requires for its local task -- which we call receiver-conditioned communication. The receiver agent passes the sender a small description of its information needs, which serves to filter and compress the sender agent's KV cache.

+

CacheBack is a simple, robust, training-free instance of receiver conditioning based on the sender's attention weights. On FanOutQA, CacheBack with Qwen 3 removes 75% of the state the agent would otherwise receive, improving accuracy by 14.7 percentage points and reducing median task-completion latency by 3.2× relative to text communication. We show comparable improvements across model families that span dense Transformers, Mamba-attention hybrids, and sliding-window attention.

+

A KV cache stores intermediate state from the text a model has processed. Abstract from the published paper, by Rossi et al. CC BY 4.0; emphasis added.

+
+
+
+
+
+
+

How it works

+

The receiver describes what it needs for its next task. CacheBack uses that request to select part of the sender’s internal numerical state, or latent state, to send back.

+
+
+
+

Sender

Select state using
the request

+ +

Receiver

Has the next task

+
+
+

CacheBack

+

Our simplest implementation.
Robust and training-free.

+

Uses attention to the receiver’s request to score sender positions, then selects a subset within the message budget.

+
+
+
What crosses the handoff?

CacheBack selects positions using the sender’s attention to the receiver’s request. In the paper’s selected-embedding channel, the corresponding input vectors are sent and the receiver rebuilds its KV cache. A position is not an isolated fact, and an attention score is not a guarantee of relevance. The experiments use matching models; cross-model translation is outside this work. Read the method and limitations.

+
+
+

Results

On FanOutQA, three agents read separate sources and send state to one answering agent. These curves compare accuracy and completion time across message budgets and text-sender sizes.

+
+

Accuracy and completion time

Higher is more accurate. Further left is faster. Each point is a measured setting; lines join the best observed tradeoffs within each method. Text points vary sender size; CacheBack points vary compression or message budget. The receiver stays fixed.

Reading r4, r8, r16: rX means keeping about 1/X of the sender’s sequence positions. For example, r4 keeps 25%, r8 keeps 12.5%, and r16 keeps 6.25%. Larger numbers mean more compression and a smaller message.

+
● ━ CacheBack▲ ┄ Text communication× Question only
+
+
FanOutQA, Qwen 3 8B: CacheBack r4 reaches 55.3% strict accuracy at 192 seconds, compared with 40.7% at 612 seconds for same-size text; weaker settings are also plotted.
Qwen 3: r4 improves strict accuracy from 40.7% to 55.3% and median completion from 612 to 192 seconds.
+
FanOutQA, Nemotron Nano 2 12B: CacheBack r8 reaches 50% accuracy near 102 seconds versus 38.7% near 131 seconds for same-size text. A smaller text sender is faster at lower accuracy.
Nemotron: the benefit also appears in a model combining Mamba and attention. A smaller text sender is faster, but less accurate.
+
+
Repeated handoffs: LongBench v2

On LongBench v2 Easy, four agents read successive sections of a long document. A final receiver answers from the last handoff. Evidence from the beginning must survive the chain.

A relative budget uses the rX fraction above, so message size grows with the sender’s context. A fixed budget caps the number of message positions, as in the labels “32K fixed” and “64K fixed”.

+
● ━ CacheBack · relative budget■ ━ CacheBack · fixed budget▲ ┄ Text× Question only
+
+
LongBench v2 Easy, Qwen 3 8B: both relative and fixed CacheBack budgets include settings faster and more accurate than same-size text. Stronger compression eventually lowers accuracy.
Qwen 3: both message-budget schemes improve the measured tradeoff. More aggressive compression eventually reduces accuracy.
+
LongBench v2 Easy, Nemotron Nano 2 12B: CacheBack r8 reaches 48% accuracy near 133 seconds, while fixed-budget settings show a different tradeoff; smaller text senders can be faster.
Nemotron: a fixed budget caps message positions; a relative budget grows with the material read. Neither denotes total GPU memory.
+
+
+

Redrawn from the paper’s plotting data for Qwen and Nemotron. Each benchmark uses 50 tasks submitted together on eight H100s; completion includes queueing. Accuracy averages three receiver draws. Qwen uses a 0 to 1,000 s time axis, Nemotron 0 to 400 s; each model keeps its scale across benchmarks. Figures 5, 11, and 12 in the paper.

+

About “94% CacheBack”: r16 retains one sender position in sixteen, removing 93.75%. The selected Qwen result above uses r4, or 75% fewer positions. Position reduction is not total GPU memory saved.

+
+
+
+
+

Watch the demo

Seven workers help a coordinator fix a Django bug. Compare latent handoffs with written reports.

+
+

36 seconds · 4K · Recorded coding task

Fixing a Django bug with seven coding agents

Qwen3-8B produces the patch 4.41× faster with CacheBack than with written reports on this case. Both runs make the same one-line code change and pass all 88 tests.

+
+

One recorded case: CacheBack 25.66 s; text 113.21 s. Startup and test grading excluded. Silent video; playback speed varies. Open in full window

+
Recording details and text description

Seven Qwen3-8B workers pass information to a coordinator. The supplied bug report identifies a missing save_m2m() call in Django’s user creation form. Both runs add that call after saving the user. The CacheBack run finishes while the text workers are still generating reports.

The interface is reconstructed from separate recorded runs, aligned at their start. The final response and patch come from the recorded outputs. Both patches subsequently pass one new test and 87 regression tests; grading is outside the clocks. This is an individual demonstration, not an aggregate benchmark. Recorded results

+
+
+
+

Recorded model run

Where should Maya collect her pass on Friday, and what ID should she bring?

Three documents contain the booking, a change of location, and the new desk’s ID rules. The final agent must connect all three.

+
+
+

CacheBack

3.42 s
+

Maya should collect her pass at Harbour Hub on Friday, and she should bring a passport as her ID.

+
Evidence quoted by the model
Evidence: +- "Reference J7 has moved to Harbour Hub." +- "Harbour Hub requires a passport for replacement building pass collections."
+
+
+

Text messages

26.09 s
+

Maya should collect her pass at the assigned desk based on her reference J7, not at the Central Desk. She should check the Friday operations notice using her reference J7 to confirm the exact location. The ID she should bring depends on the desk where she collects her pass. If she is collecting at Harbour Hub, she must bring a passport, as a driving licence is not accepted. The name on the ID must match her booking, and the ID requirements for the specific desk apply.

+
Evidence quoted by the model
Evidence: +- "Maya should collect her pass at the assigned desk based on her reference, not at the Central Desk." +- "She should check the Friday operations notice using her reference J7 to confirm the exact location." +- "If she is collecting at Harbour Hub, a passport is required, and a driving licence is not accepted."
+
+
+

Qwen3-8B · one A100 · r4 · one warm run per method. Times include three handoffs and final answer generation, excluding model loading, tokenization, and warmup. This recording is an example, not a benchmark. Raw recording · Setup

+
Replay the booking handoffs +
Open full window
+
+
+
+ +
+
+

Quickstart

Bind a sender and receiver to matching models, then pass the receiver’s request to rcc.transfer. CacheBack is the default selector. Continue generation with your model’s native API.

Code and documentation

Local Qwen 3 weights, using Hugging Face or vLLM.
Hosted chat APIs do not expose the required state.

Python
import rcc
+
+sender = rcc.bind(
+    model, tokenizer,
+    messages=sender_history, backend="hf",
+)
+receiver = rcc.bind(
+    model, tokenizer,
+    messages=receiver_history, backend="hf",
+)
+await rcc.transfer(
+    sender, receiver,
+    "Who owns the Cedar booking?",
+)
+inputs = receiver.pop()

Model, tokenizer, and histories loaded; run in an async function or notebook. Runnable quickstart

+

THE PAPER

Receiver-Conditioned Latent Communication gives 94% CacheBack

Maximillian Rossi, Prajwal Raghunath, Haoqing Xuan, Yusen Zhang, and Eugene Wu.

Read the PDFReproduce the paper
Cite this work BibTeX
@misc{rossi2026cacheback,
+  title = {Receiver-Conditioned Latent Communication
+           gives 94\% CacheBack},
+  author = {Rossi, Maximillian and Raghunath, Prajwal
+            and Xuan, Haoqing and Zhang, Yusen
+            and Wu, Eugene},
+  year = {2026},
+  eprint = {2609.32046},
+  archivePrefix = {arXiv},
+  primaryClass = {cs.AI},
+  url = {https://arxiv.org/abs/2609.32046}
+}
+
+ +
