mhcmatch — which neoantigens are presented, and which ones a T cell will see

Pure Python, no compiled extension beyond the seqtree search core, MHC-I and MHC-II, human and mouse. Every reference dataset is fetched from isalgo/pmhc_data on first use, so a fresh pip install runs every example in this file with no manual downloads.

pip install mhcmatch
mhcmatch bootstrap                                   # pre-fetch the panel (optional; ~16 MB)

# rank a donor's neoantigen candidates end to end
mhcmatch rank fasta candidates.fasta --alleles donor.alleles --cls mhc1 --tumor SKCM --out ranked.tsv

Pick your entry point

your question	command	Python
Which of these peptides does an allele present?	mhcmatch predict f.fasta --cls mhc1	predict.predict_fasta
Which allele presents this peptide?	mhcmatch restriction PEP --calibrated	store.restriction
Is it a binder at all, one number?	mhcmatch binder PEP	store.binder_score
What is the IC50, and vs its wild type?	mhcmatch affinity PEP --wt WTPEP	store.affinity_model
Will a T cell respond to it?	mhcmatch complement --peptides p.txt	complement.score
Rank neoantigen candidates for a donor	mhcmatch rank fasta ...	rank.rank_fasta
…with mimicry risk and what each one resembles	mhcmatch rank ... --extended --annotate	mimicry.score
Why did this candidate rank there?	mhcmatch explain PEP --allele A	—
What self / viral / bacterial peptide does it mimic?	mhcmatch mimics --peptides p.txt	mimics.neighbours
Does that mimicry raise or lower the risk, and why?	mhcmatch mimicry --peptides p.txt	mimicry.score
Has this, or something near it, already been tested?	mhcmatch neoag --peptides p.txt	mimicry.annotate
Where in the proteome does it come from?	mhcmatch source --peptides p.txt --proteome human	Proteome.find_sources
Is the gene on in the tumour, and in normal tissue?	mhcmatch expression --list-contexts	expression.lookup
What does this allele's motif look like?	mhcmatch logo 'HLA-A*02:01'	logo.motif
Which peptides in this protein are presented?	mhcmatch scan p.fasta --correction bh	store.scan_protein
What is the full MHC-II ligand around this core?	mhcmatch span CORE --protein p.fasta	ligand.presented_span

predict is the presentation axis (is it presented at all, the NetMHCpan %Rank_EL analogue); restriction is the specificity axis (which allele). They answer different questions and a peptide can top one and not the other — NLVPMVATV is unambiguously A*02:01-restricted yet bands mid-pack against A*02:01's own ligands.

Batch and threads — read this before scripting a loop

Pass --peptides FILE to any peptide-keyed command. The expensive part of most of them is setup that a per-peptide invocation pays again every time: the presentation and affinity calibrators are ~5 s, the binder calibrator ~45 s, a human-proteome length index ~70 s. All of it is cached for the life of the process, so one process over a whole list is the difference between 49 s per peptide and thousands per second. Measured, both ways, in bench/cli/.

mhcmatch binder     --peptides peptides.txt --alleles "$ALLELES" --top 1 --out binders.tsv
mhcmatch complement --peptides peptides.txt --prior 4.2e-4       --out recognition.tsv
mhcmatch affinity   --peptides pairs.tsv --allele 'HLA-A*02:01'  --out affinity.tsv   # pairs.tsv has
                                                                     # peptide + wt_peptide columns
mhcmatch source     --peptides peptides.txt --proteome human --threads 0 --out sources.tsv
mhcmatch mimics     --peptides peptides.txt --categories thymus,viral,bacterial --threads 0
mhcmatch mimicry    --peptides candidates.tsv --annotate --out risk.tsv   # + what was hit
mhcmatch neoag      --peptides candidates.tsv --out annotated.tsv  # keeps every original column
cut -f1 table.tsv | mhcmatch complement --peptides -              # `-` reads stdin

The input is one peptide per line, or a TSV with a peptide column (.gz fine); the output is TSV with a header on stdout or --out. --threads is offered only on source and mimics, whose neighbour search runs in C++ with the GIL released; everywhere else the per-peptide work is a small numpy product and a thread pool would buy nothing, so the flag is absent rather than ignored.

The two axes

Presentation is necessary and not sufficient: most presented peptides are ignored. mhcmatch keeps the two questions apart and combines them with a gate (a product of sigmoids), not a sum, so a candidate that fails either one cannot be rescued by the other.

Presentation — per-allele %rank / P(present) / band from a learned anchor model with cross-allele pseudosequence diffusion (rare alleles borrow from groove-similar frequent ones), a K=3 motif mixture and per-allele register EM for class II; plus a pan-allele Potts affinity head (IC50 nM, Łuksza amplitude A = Kd_WT/Kd_MT, DAI). Their calibrated combination is the generalized binder score (binder_rank), the recommended single-number binder index.

Recognition — mhcmatch.complement, a prior-free log-odds over six blocks: physicochemistry and length; the same components split MHC-facing vs TCR-facing; MJ1996 on the anchors and TCRen marginalised over 28 M real CDR3 loops on the TCR-facing side; contiguous-hydrophobic-run motifs; per-role residue log-odds, now with per-length (8/9/10/11+) and relative-position tables; and adjacent TCR-facing dipeptides. Fitted per species and never pooled across hosts. Vectorised — a whole published corpus scores in seconds, so pass a list. mhcmatch.posbayes and mhcmatch.ipred are strict special cases of it and ship alongside for comparison.

Evidence that outranks a model. mhcmatch.known carries five reference sets built from the public deposits — confirmed tumour neoantigens, peptides the screens tested and found non-immunogenic, IEDB-immunogenic epitopes, the thymic self-immunopeptidome, the viral ligandome. An exact match is stronger evidence than any score, so rank reports it as a flag and floats those candidates into a tier of their own instead of folding it into the number.

Pick your tumour type. mhcmatch expression --list-contexts prints all 19 TCGA↔GTEx pairings; expression.matched_tissues('BRCA') gives the matched normal and expression.lookup(gene, tumor='BRCA') the tumour value. The benchmark's own expression term is a GTEx cross-tissue median so that it is identical on fit and holdout — that is a comparability requirement, not a recommendation, and a real ranking run should pass its own tumour type.

Expression, and which normal tissue to compare against. --tumor takes a TCGA study abbreviation (SKCM, LUAD, …; CRC merges TCGA's COAD and READ) and --tissue a GTEx SMTSD name (Skin - Sun Exposed (Lower leg)). Neither is a clinical coding system — not ICD-O-3, SNOMED CT or OncoTree — so a pipeline needing one brings its own crosswalk. expression.matched_tissues("SKCM") gives a tumour type's matched normal, which is what makes the safety read askable without knowing the pairing by heart; mhcmatch expression --list-contexts prints all 19 pairings and the 31 tissues that are safety-read-only. HNSC is marked approximate — GTEx has no head-and-neck mucosa.

Cross-reactivity. mhcmatch.mimics reports near-identical reference peptides per category, and never sums them, because a hit in each argues something different: thymus (presented during negative selection — tolerance, and autoimmune risk for a vaccine), self (encoded but not known to be presented), viral / bacterial (a pre-existing repertoire may cross-react, raising immunogenicity), neoag (already tested somewhere).

Mimicry as risk. mhcmatch.mimicry is the fitted form of that scan: viral, self and thymus, each split into an anchor and a TCR-facing channel that partition the peptide, as six signed log-odds contributions and their sum. A single whole-peptide distance is the wrong feature and the sparsity that suggests otherwise is a search artifact — whole-peptide radius-2 thymic coverage is 1.63 %, while the TCR face at radius 1 reaches 53.4 %. Signs follow the reference, as designed: viral positive on both channels, self negative on both, thymus positive on its anchor. MimicryScore.nearest carries which peptide was hit and what protein it came from, so mimicry.safety() reaches expression.safety_profile — a bare distance cannot. Scores are log-odds; probability() needs a named corpus, because the seven screens behind the calibration run from 0.048 % to 46.8 % positive. Report the within-screen AUROC (0.596), not the pooled one (0.849). The tested-neoantigen database is mimicry.annotate / mhcmatch neoag — prior evidence, and deliberately never a fitted term, since every labelled screen we hold sits inside it.

Building the cassette. mhcmatch.vector is the step after ranking: withdraw on safety, then how many units each allotype carries, in what order, joined by what. screen() excludes rather than down-ranks — the second-best cassette is cheap, myocarditis is not — and it screens every register of a 27-mer unit, not the mutated one, against near-exact self origin joined to tissue expression. select() grows each allotype while the next candidate beats that allotype's own expected yield per slot, so diversification falls out of the arithmetic instead of a quota; order() tries no spacer first and picks the layout minimising the strongest predicted binder spanning each junction; slippery_sites()/deslip() remove the m1Ψ +1-frameshift motif, which matters more for a concatemer than for a natural ORF.

Both ends join to the rest of the library. --context windows.fasta takes rank's minimal epitopes and rebuilds them as long units against the FASTA they were called on, one per variant rather than one per register — a minimal peptide loads onto any cell without costimulation and is the tolerising configuration, so the reader will not take one. --fasta-nt writes the coding sequence: highest-usage human codon per residue, backed off to shorten homopolymers, then deslipped. It is not a codon optimiser — it fixes the two things that break a concatemer specifically and leaves GC, structure and CpG to the manufacturer's tooling.

mhcmatch rank fasta windows.fasta --alleles "$HLA" --out ranked.tsv
mhcmatch vector --candidates ranked.tsv --context windows.fasta --n0 8 --screen \
    --fasta cassette.faa --fasta-nt cassette.fna

⚠️ mimicry is a scoring term, not a safety screen. Flagging candidates by "resembles a tolerance-side reference" fires on almost everything — influenza GILGFVFTL drew 14 essential-tissue hits — because anchor-masked similarity to a presented reference is presentation, not recognition. Exclusion goes through vector.self_origin_risk (bench/results/vector_safety_screen.md).

Model names

Every fitted model is named by the acronym of its parameters — aggregate5 and "the full model" said nothing about what was in them, and two designs were once both "the neoantigen model". One letter per parameter, in a fixed canonical order:

letter	parameter	from	what it is
P	presentation	AnchorModel	-log10 of the per-allele %rank; fitted on observed ligands
B	binder score	predict.binder_score	-log10 of the calibrated combined %rank (Fisher of P and A)
A	affinity	PottsAffinity	-log10 of the Potts IC50 %rank; fitted on measured IC50
D	differential agretopicity	PottsAffinity.dai	log10(Kd_WT / Kd_MT) vs the recovered wild type
E	expression	mhcmatch.expression	log1p(TPM), observed or reference-imputed
V	vanilla physicochemistry	mhcmatch.ipred	the 13-parameter calibrated log-odds
C	complementarity	mhcmatch.complement	the six-block recognition log-odds
F	foreignness	viral IEDB ligandome	distance to the nearest viral epitope
M	mimicry	mhcmatch.mimicry	the six-channel signed aggregate

So PADEC is presentation + affinity + agretopicity + expression + complementarity, and PADECM adds mimicry. Suffixes are fitting choices rather than parameters: -bal (every screen weighted to the same total mass), -scr (screen indicators as nuisance columns).

V is "vanilla", not "ipred". ipred is the old recognition term and complement is what replaced it — the same axis at two generations, with ipred a strict special case of complement. Naming the letter after the generation rather than the module makes BDEVF legible as "the old model" at a glance.

P is not a second affinity term. Both end up as a %rank against the same kind of background, so the mechanism doesn't separate them — the training data and the target do. A is a Potts model fitted on measured IEDB IC50, targeting Kd: the biophysics of the groove. P is the AnchorModel fitted on the observed ligand panel, targeting how ligand-like a peptide is, which carries processing, transport and abundance signal that binding alone does not. That is the field's binding-affinity vs eluted-ligand split, and the two are measurably not redundant — on TESLA-608 A scores 0.757 AUROC, P 0.763, and their Fisher combination B 0.786. A combination cannot beat both parents by that margin on the same measurement twice.

P is a rank, not a similarity search — worth stating because the name invites the other reading. It is a score against a random-peptide background (10,000 peptides matched to the corpus's amino-acid and length distribution). Nothing is retrieved: no reference peptide is looked up and no anchor-matched protein is searched for. A and B are the same, so the whole presentation side is scoring, not retrieval. The searches are restriction (the epitope panel, anchor-masked — not in any acronym), M (thymic/viral/proteome windows) and F (the viral ligandome).

Python

import mhcmatch
from mhcmatch import complement, known, mimics

store = mhcmatch.Store.from_pmhc(tier="shortlist", species="human")   # auto-fetched from HF, cached

store.restriction("NLVPMVATV", calibrated=True)      # ranked alleles + %rank / P(present) / band
store.binder_score("NLVPMVATV")                      # the single-number binder index
store.scan_protein(my_protein, cls="mhc1")
store.decompose("NLVPMVATV")                         # anchor / TCR-facing split, with X masks

aff = store.affinity_model("mhc1")
aff.predict_ic50("NLVPMVATV", "HLA-A*02:01")             # ~64 nM
aff.amplitude("NLVPMVATL", "NLVPMVATV", "HLA-A*02:01")   # Kd_WT/Kd_MT (Łuksza eq. 9)

complement.score(peptides)                           # vectorised: pass the list, not a loop
complement.posterior(peptides, prior=4.2e-4)         # the log-odds carries NO prior; supply yours
complement.score(peptides, species="mouse")          # separate table; the hosts are never pooled

known.lookup("GILGFVFTL")                            # -> 'viral'
mimics.neighbours(peptides, ref_sets, threads=0)     # threaded C++ neighbour search

pm = mhcmatch.Proteome.from_hf("human")
pm.find_sources(peptides, max_subs=1, threads=0)     # batch; find_source() is the single-query form
pm.wildtype("NLVPMVATV")                             # the WT counterpart, for agretopicity

Full API: antigenomics.github.io/mhcmatch. Six marimo notebooks in notebooks/ run the workflows end to end on whole published deposits (pip install 'mhcmatch[notebooks]').

Data

Everything is fetched on demand from isalgo/pmhc_data and cached by huggingface_hub; $MHCMATCH_PMHC_DIR points at a local mirror instead.

mhcmatch bootstrap                              # the reference ligand panel, both tiers (~16 MB)
mhcmatch bootstrap --proteome human,mouse       # + reference proteomes
mhcmatch bootstrap --reference                  # + corpora, known-epitope, mimicry, expression (~115 MB)

Pseudosequences (34-mer grooves) and the fitted model parameters are vendored in src/mhcmatch/data/ with their PROVENANCE.md. Nothing is refitted at import.

Deployment

integrations/nextflow/mhcmatch/ is a self-contained nf-core-style module (main.nf, nextflow.config, environment.yml, Dockerfile) that drops in for MHCflurry class I and the class-II binding subworkflow, consuming the same (meta, peptide.fasta, alleles) channel and emitting a pipeline-compatible .scored.csv. The image bootstraps its panel at build time, so compute nodes need no network.

Benchmarks

Harness and result tables live in 2026-mhcmatch-benchmark. Paths like bench/results/... resolve there.

Head-to-head against NetMHCpan-4.2b / NetMHCIIpan-4.3i on the same per-(peptide, allele) task, stratified by allele rarity, with bootstrap CIs and paired significance (bench/compare/SOURCES.md for provenance and caveats):

• Immunogenicity ranking on TESLA-608 (608 candidates, 37 T-cell-validated; predictor-agnostic, every tool scores it independently) — mhcmatch's binder_score 0.786 AUROC vs NetMHCpan 0.747; each single head also beats it (affinity 0.757, presentation 0.763). bench/results/immuno_binder_score.md.
• Allele specificity, MHC-I — mhcmatch beats NetMHCpan on medium and frequent alleles on AUROC, AUPRC and PPV@k (all p < 0.001; frequent AUPRC 0.850 vs 0.769). Rare is a wash (p = 0.41).
• Presented-vs-random screening — mhcmatch wins MHC-I frequent (AUPRC 0.881 vs 0.846, p = 0.001); medium and rare sit inside the CI. Both tools are ≥ 0.97 here.
• MHC-II — mhcmatch wins the rare stratum on both tasks; NetMHCIIpan leads medium and frequent. That gap is one locus, not the class: DP averages −0.305 AUPRC while DR is at parity or better (+0.010), and the mechanism is a register-EM convergence failure on DPA1*02:01 that register_em="converge" closes 28 % of. bench/results/register_em_convergence_dp.md.
• Mouse MHC-II — mhcmatch wins all nine cells on specificity.
• Speed — MHC-I ~195k–260k peptide-allele scores/s (~68× NetMHCpan); MHC-II ~19k/s (~6.6× NetMHCIIpan), heavier because of 3 mixture components × ~7 register frames.
• Recognition — the complementarity score beats the shipped posbayes sum on all four corpus arms and both hosts under peptide-grouped CV; the per-length and relative-position role tables add +0.007 to +0.021 AUROC on top, with paired bootstrap CIs excluding zero on every arm. bench/results/complementarity.md, bench/results/length_roles.md.

Read the class-II numbers with compare/SOURCES.md in hand: NetMHCIIpan trained on essentially all public IEDB eluted-ligand data, so its in-corpus medium/frequent strata are contaminated in its favour and the rare / zero-shot axis is the fair comparison.

Naming a class-II restriction

Class-II alleles are reported in NetMHCIIpan's own form — DRB1_0101 for DR (DRA is monomorphic, so the beta chain names the molecule) and HLA-DQA10501-DQB10301 for the DP/DQ heterodimers. The two forms do not lead with the same chain: DR leads with its beta, DP and DQ with their alpha. Code that compares two callers by pulling the leading gene out of the key is therefore matching DR's beta against DP/DQ's alpha, and splitting DR against itself whenever the DRB gene differs (DRB1 vs DRB3). Both mistakes are easy to make and neither announces itself.

--mhc2-report picks the granularity, on every command that chooses an allele (restriction, binder, scan, predict, rank):

mhcmatch restriction PKYVKQNTLKLAT --cls mhc2 --mhc2-report isotype

mode	DRB1_0101 becomes	HLA-DQA10501-DQB10301 becomes	use it for
pair (default)	DRB1_0101	HLA-DQA10501-DQB10301	reporting, and string-comparing against NetMHCIIpan
beta	DRB1*01:01	DQB1*03:01	comparing alleles across isotypes on the same chain
isotype	DR	DQ	"did the two callers pick the same molecule family"

mhcmatch.pseudoseq.class2_report(key, mode) is the same reduction from Python. Commands that are handed an allele (affinity, explain, logo) echo back what the caller typed.

Development

bash setup.sh            # repo-local .venv + editable install (uses a sibling ../seqtree if present)
bash setup.sh --tests    # + pytest
pytest -q

Theory and derivations are in the manuscript repo (appendix/mhcmatch.tex); what is planned and what is in flight is in ROADMAP.md and CHANGELOG.md.
